Handrail PB 2816
Durability and
Perfect Fit
The PB 2816 profile is produced with high-performance rubber, ensuring resistance, durability, and safety for escalators and moving walkways.
Benefits:
- Compatible with various escalator and moving walkway models
- High-performance rubber for continuous use
- Custom production, according to the required length
- Comfort and adherence for users
Please inform the brand and model of your escalator or moving walkway and the handrail measurement in meters via WhatsApp. Get your fast quote with EBC BRASIL.
Specifications
Our products are made with precision and are compatible with the main escalator and moving walkway models and brands, ensuring the equipment efficient operation and meeting the technical requirements of each escalator and moving walkway.
Manufacturers and models of escalators and moving walkways that use the PB 2816 profile:
Xizi, Otis UBSL/NCE, Thyssen Tugela/Velino, and Orinocco.
Dimensions and tolerances:
| Profile | A (mm) | B (mm) 2 sides | C (mm) | D (mm) | E (mm) | Length tol. (mm) | Shore – A Hardness |
|---|---|---|---|---|---|---|---|
| PB 2816 | 76,0 – 2,0 | 28,0 ± 1,0 | 38,0 +2,0 | 60,0 – 2,0 | 9,5 ± 0,5 | ± 15,0 mm | 75 ± 5 |
| Profile | A (mm) | B (mm) 2 sides | C (mm) |
|---|---|---|---|
| PB 2816 | 76,0 – 2,0 | 28,0 ± 1,0 | 38,0 +2,0 |
| D (mm) | E (mm) | Length tol. (mm) | Shore – A Hardness |
|---|---|---|---|
| 60,0 – 2,0 | 9,5 ± 0,5 | ± 15,0 mm | 75 ± 5 |
